Application for Calculation of Timing Belts

SynchroBelt Flash Screen

SynchroBelt supports the calculation of the

  • dimensioning problem with automatic belt selection
  • verification problem for a given belt
  • geometry of the pulleys
for a given load and transmission ratio.

User Interface

SynchroBelt is a multi-lingual application for Microsoft Windows. The user can select a language for the user interface and output out of:

  • Dutch
  • English
  • French
The user interface is very user friendly: the application guides the user through each calculation sequence.

Identification of a Calculation Project

At the start of a new calculation project a dialog box is being opened for input of some data for the identification of the calculation project. This dialog box contains edit controls for input of: order, project, subproject, item, ID wheel 1 and wheel 2, calculated by, organization, and date of calculation. A text box is also provided to hold a short note about the calculation project.

Dimensioning a Timing Belt Transmission

The objective is the dimensioning of a timing belt transmission for a given load and transmission ratio.

Input of load in power or torque and rotation speed at the pinion, or torque and rotation speed at the wheel. A list with timing belt records is loaded from disk. The application will determine which item of the timing belt list satisfies the load condition.

Timing Belts List

A list with timing belts is supplied with the application executable file. This list can be managed with a dialog box. The user can create his own list with timing belts derived from commercial catalogues. See dialog in verification calculation.

Go to next web page to see for input of timing belt design specifications.
